Size 42mm NEMA17 Brushless DC Motor 24V 64W 3000RPM 0.2Nm with Electromagnetic Brake

Size 42mm NEMA17 Brushless DC Motor 24V 64W 3000RPM 0.2Nm with Electromagnetic Brake

$60.00

In Stock:

10

Model: 42AI70-2430YS

Weight: 0.55KG

Certificated: ISO, CE, RoHS

Ships From China

10 in stock (can be backordered)

42mm BLDC Motor with Brake: This size 42mm 3 phase brushless dc motor has a body length 104mm with 24v electromagnetic brake, rated voltage 24v and a moderate rated speed 3000rpm, which can reach 64w power and 0.2Nm torque output. Its high performance with square body and reasonable design makes this bldc motor widely used for textile machines, robotics, autobikes, cooling fans, pumps, household appliances, and other industrial applications, etc.

42mm BLDC Motor with Brake Specification

42mm BLDC Motor with Brake

  • Part Number: 42AI70-2430YS
  • No. of Phases: 3
  • No. of Poles: 8
  • Rated Voltage: 24V
  • Rated Speed: 3000RPM
  • No-loading Speed: 4000RPM
  • Rated Torque: 0.2Nm
  • Rated Curent: 3.5A
  • Rated Power: 64W
  • Insulation Class: B
  • Brake Type: Electromagnetic
  • Brake Voltage: 24VDC
  • Frame Size: 42x42mm
  • Body Length: 70mm
  • Shaft Diameter: Φ5mm
  • Shaft Length: 24mm
  • Number of Leads: 8
  • Lead Length: 1000mm
  • Sensor: Hall Sensor
  • Weight: 0.8kg

Overalll Size

If you need a PDF data sheet, please feel free to email: info@frankhumotor.com.
